Description
Material: Full titanium alloy frame
Dimensions (L×D×H): 4000×4000×1550mm (Spread); 1850×1850×1550mm (Fold)
Wheelbase: 4000mm
Blade: 64-inch coaxial
Max take off weight: 510kg (0 altitude)
Maximum load: 200kg (0 altitude)
Maximum flight time: ≥15min
Maximum level flight speed: 10m/s
Maximum ascent speed: 4m/s
Maximum descent speed: 4m/s
Maximum pitch angle: 20°
Maximum rotational angular velocity: pitch axis:120°/s；heading axis:120°/s
Hovering accuracy: vertical ±0.5m；level ±1.5m (When GPS positioning is working normally)
Wind resistance capacity: Safe takeoff and landing ＜8m/s
Operating temperature: -10℃～45℃
